1.Input voltage: AC100~240V 50/60Hz
2.Power consumption:≤100W
3.Scanner: 25kpps , scan angle:max±30°;Input signal:±5V;Linearity distortion<2%
4.Motor: 3 phase 42 motor 2pcs
5.X axis 540° rotation,Y axis 270° rotation
6.Beam diameter and divergence:3*6.5mm;1.5mrad
7.Control mode:music (black out)/ automatic/master-slave/DMX512(6/40CH)/ILDA
8.Control interface:3 pin DMX512/25DB ILDA
9.DMX effect: Single pattern mode,and with the function of unique blanking,strobe,
rotation, movement, billowing, zoom,write in,speed and color etc.
10.Operating requirement: dry, less dust, 0~35℃(environmental temperature),will reduce the attenuation of the diode and extend the life of the light.
11.Carton size: 34.5*23*48cm Gross weight: 9.5 kg
|
